30" 4 Burner Gas Downdraft Cooktop

Model: KCGD500GSS

Model: KCGD500GSS

30" 4 Burner Gas Downdraft Cooktop

Name: 30" 4 Burner Gas Downdraft Cooktop
Brand: KitchenAid
SKU: KCGD500GSS
Price: 2249.0 USD
Availability: InStock
Rating: 4.28 (920 reviews)

KCGD500GSS

Model: KCGD500GSS

Hurry! Limited Time Offer Ends Soon

Compare

DOES IT FIT IN YOUR SPACE?

Use your camera to view in your room.

Compare

Key Features

•

Downdraft Ventilation

•

17K BTU Professional Burner

•

5K BTU Even-Heat™ Simmer Burner

•

300 CFM Exhaust Rating

•

3-Speed Fan Control

Color:

Stainless Steel

Hurry! Limited Time Offer Ends Soon

Please enter a valid email You have already submitted your email.

* I agree to the Terms of Use and acknowledge the Privacy Notice. Please agree to the Terms of Use and Privacy Notice to proceed.

in.stock.toast.message

to check availability in your area.

Estimating In-Home Delivery for ...

Earliest Estimated In-Home Delivery :

Protection Plans (Optional)

Flexible Appliance Protection Plans for Your Needs Learn More

Limited Standard Warranty included

Accessories & Attachments

Items frequently bought together

Cooktop Downdraft Ductless Vent Grease replacement filter

Ductless Downdraft Vent Kit, Black, Size: 20" L x 13" W x 12" H

Overview

Product Description

30" 4 Burner Gas Downdraft Cooktop

This 30” gas cooktop includes Downdraft, an integrated ventilation system that doesn’t require a separate hood. The cooktop features a 17K BTU professional burner to achieve both high heat needed for searing and low simmer settings. The 5K BTU Even-Heat™ Simmer Burner enables precise simmering and melting while the 300 CFM exhaust rating means the venting can handle it all.

Downdraft Ventilation

Integrates the ventilation system into the cooking surface so that a separate hood is not needed. Smoke and odors can be removed and taken outside or filtered and recirculated inside. A duct-free kit is available for purchase separately.

17K BTU Professional Burner

Provides the ability to use high-temperature cooking methods such as searing, stir-frying, and wok cooking as well as low temperatures suitable for simmering.

3-Speed Fan Control

Can be precisely matched to cooking needs, effectively removing steam, grease, and odors from the air.

Convertible to Duct-Free Ventilation

Allows a downdraft cooktop to be placed nearly anywhere in the kitchen using a duct-free conversion kit (not included). This filters and recirculates the air without running ductwork, ideal for kitchens with installation restrictions or ducting limitations.

Additional Features

5K BTU Even-Heat™ Simmer Burner

A diffuser plate allows more control of the flame at the lowest setting, for more precise simmering and melting.

300 CFM Exhaust Rating

Handles the venting requirements of high temperature cooking techniques like pan searing and stir-frying.

15K BTU Professional Burner

Reaches the high temperatures required to quickly get liquids to a boil and for high-temperature cooking techniques including getting a great sear on meat.

Melt Cap

Melt chocolate or butter, simmer delicate sauces, or poach eggs on a low-power burner, thanks to a wider burner cap that shields and diffuses the flame to produce a gentler, low-power heat.

Electronic Ignition and Automatic Re-Ignition

Lights burners with an electric spark instead of a pilot light. For more reliable performance, burners are relit if the flame is blown out.

Stainless Steel Knobs

Enhance the look of the cooktop surface with sturdy construction that adds to their premium feel.

Full-Width Cast-Iron Grates

Enhance the beautiful look of the cooktop and allow easy movement of cookware around the entire cooking surface.

LP Conversion Kit

Allows you to convert the cooktop so it can be used with LP gas.

Height:

46.83, 18-7/16”

centimeters, inches

46.83 cm

18-7/16 in

Width:

76.20, 30”

centimeters, inches

76.20 cm

30 in

Depth:

54.61, 21-1/2”

centimeters, inches

54.61 cm

21-1/2 in

Download Specs Sheet

Download Dimension Guide

Certifications

ADA Compliant

Prop 65

CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Yes

Exterior Details

Knob Color

Stainless Steel

Knob Type

Metal

Cooktop Details

Cooktop Surface Color

Color Coordinated

Cooktop Surface Material

Stainless Steel

Digital Display

Heating Element On Indicator Light

Hot Surface Indicator Light

Ignition Type

Flame-Sensing™ Re-ignition

Installs Over Built-In Oven

Dimensions

Common Size

76.20 cm, 30 in

Cutout Depth

50.64 cm, 19-469/500 in

Cutout Width

72.71 cm, 28-5/8 in

Depth

54.61 cm, 21-1/2 in

Gross Weight

35.38 kg, 78 lbs

Height

46.83 cm, 18-7/16 in

Net Weight

29.94 kg, 66 lbs

Width

76.20 cm, 30 in

Element/Burner Details

Automatic Pan Detection

Cooktop Element Style

Sealed Burner

Cooktop Type

Downdraft

Left Front Element-Burner Power

17,000 BTU

Left Front Element-Burner Type

Burner

Left Rear Element-Burner Power

5,000 BTU

Left Rear Element-Burner Type

Even-Heat™

Number of Cooking Element-Burners

Number of Grates

Power Boost

Right Front Element-Burner Power

10,000 BTU

Right Front Element-Burner Type

Burner

Right Rear Element-Burner Power

15,000 BTU

Right Rear Element-Burner Type

Burner

Controls

Control Location

Right Side

Control Type

Knobs

Number of Vent Speeds

Details

Digital Display

Fuel Type

Gas

Installs Over Built-In Oven

LP Convertible

Yes

Power Outage Compatible

Yes

Ventilation Details

CFM Motor Class

300

Downdraft Vent

Yes

Grate Details

Cast Iron Grates, Continuous, Matte Finish

Number of Grates

Electrical

Amps

Power Cord Included

Yes

Volts

120

Features

Cooktop Features

Downdraft Ventilation, Even-Heat Melt Burner
